Building A Project On The BlackBerry

Update 2: The Netbeans link within the body died a while back. Updated instructions for 6.7 and newer are available here.

Updated: I forgot to add the main method and UiApplication section. It is now part 9 of the instructions.

While Thorsten & myself wrote build instructions for the BlackBerry in the forum/mailing list in the past they are somewhat outdated by now and aren't as easy to find using Google. So here is a step by step guide on porting to the BlackBerry devices with some explanations of the Caveats.

The standard LWUIT won't work on the Blackberry since it references API's such as 184/226, notice that LWUIT doesn't need or use these API's when they are not available! On the Blackberry device the very reference to these API's will cause the application to fail. Furthermore, as I explained in a previous post, Blackberry devices have some "issues" when using classes compiled without the RIM toolchain and LWUIT isn't compiled with the RIM toolchain.
Last but not least, the performance and user experience of the MIDP based LWUIT on Blackberry isn't very good...

The solution for all these issues is to use the RIM API's, which unfortunately means you need to create two separate versions of your application (3 if you need blackberry Storm support) .

I won't go into too many details on the BlackBerry devices, but a couple of years ago they introduced the Storm device which was their first touch screen device (featuring a click screen). Supporting the Storm requires importing classes of the API that aren't supported in older versions of RIM's API, hence Storm compatibility requires using a relatively new BlackBerry OS that most users don't have.
So you will need two builds and two blackberry Java Development Environments (JDE's) if you need to support Storm.

The instructions bellow are also geared towards the NetBeans IDE and Ant build.

LWUIT currently has two maintained BlackBerry ports, one created by Thorsten & another created by myself. Each has its advantages and you can easily go back and forth between them. Since I used NetBeans I will explain based on my port but you can easily replace the content of the src directory with Thorsten's port and it should be pretty seamless.

A standard LWUIT MIDlet should work fine on a RIM device using the ports, however RIM also offers support for a CLDC application. Using this approach tends to provide improved performance/security handling for RIM although its completely optional.

  1. Download the JDE versions, I recommend 4.2.x and 4.7.x (for Storm support).
  2. Follow the NetBeans BlackBerry knowledge base article to add the JDE versions as platforms to NetBeans (no need to follow the part about editing the build.xml).
  3. Fetch the LWUIT sources from SVN and open the BlackBerry project. Clean & Build the project (notice that you MUST clean & build, a plain build will often fail since the RIM port needs to replace some classes from LWUIT).
  4. If using storm as well, change the configuration of the Blackberry LWUIT port to "touch" and again clean & build.
  5. Download the BB ant tasks which are much easier to work with than the approach taken by the knowledge base article.
  6. Add "configurations" to the NetBeans project for BlackBerry and BlackBerryTouch. Set them to use the appropriate JDE Platforms.
  7. In the blackberry configurations add an "Ability" called RIM. This will allow you to use #ifdef RIM
    rather than #ifdef BlackBerryTouch && BlackBerry
    (yes, I can't stand #ifdef's but they are better than just copy and pasting the entire code and with RIM we don't have a choice).
  8. In the libraries for the project add both LWUIT & the appropriate blackberry project. Make sure to add the touch JAR only to the touch (Storm) configuration and the standard jar to the other BlackBerry configuration.
  9. If you are building a CLDC UiApplication add the following to your MIDlet class definition (instead of extends MIDlet):
    public MyMIDlet extends //#ifdef RIM
    net.rim.device.api.ui.UiApplication
    //#else
    //# javax.microedition.midlet.MIDlet
    //#endif
    {

    Then add this to the body of the MIDlet:
    //#ifdef Blackberry
    public static void main(String[] argv) {
    new MyMIDlet().startApp();
    }
    //#endif

    You might want to also add similar methods for notifyDestroyed/platformRequest:
    public void notifyDestroyed() {
    System.exit(0);
    }
    public void platformRequest(String s) {
    net.rim.blackberry.api.browser.Browser.getDefaultSession().displayPage(s);
    }

  10. Open the build.xml file of your NetBeans project and add the following, update the paths and names marked in bold (notice this is geared towards a CLDC UiApplication, you might need to modify this slightly for a MIDlet):
    <target name="post-init">
    <available file="${platform.home}/bin/rapc.exe" property="do.rapc">
    <available file="${platform.home}/simulator/9500.bat" property="bbtouch">
    <condition property="jpda.port" value="8000">
    <isset property="do.rapc">
    </isset>
    </condition>

    <target name="post-preprocess" depends="copyBBSources,copyBBTouchSources">
    </target>

    <typedef resource="bb-ant-defs.xml" classpath="bb-ant-tools.jar">
    <target name="bbbuild" description="blackberry build" depends="init,copyBBSources,copyBBTouchSources">
    <echo message="Compiling ${preprocessed.dir}"></echo>
    <mkdir dir="${dist.dir}/bbant">
    <rapc verbose="true" output="${name}" jdehome="${platform.home}" import="${platform.bootclasspath}" destdir="${dist.dir}/bbant/" noconvert="true">
    <src location="${basedir}/${preprocessed.dir}">
    <jdp title="Vendor" version="1" type="cldc" icon="${basedir}/src/icon.png" />
    </jdp>
    <!-- sigtool jdehome="C:\Program Files\Research In Motion\BlackBerry JDE 4.7.0" codfile="${dist.dir}/bbant/${name}.cod" password="" / -->
    <alx destdir="${dist.dir}/bbant" filename="${name}.alx">
    <application id="AppName">
    <codset>
    <fileset dir="${dist.dir}/bbant" includes="*.cod">
    </fileset>
    </codset>
    </application>

    <mkdir dir="${dist.dir}/bbant-final">
    <jadtool description="desc" id="appId" input="${dist.dir}/${dist.jad}" destdir="${dist.dir}/bbant-final">
    <fileset dir="${dist.dir}/bbant" includes="*.cod">
    </fileset>
    </jadtool>

    <target name="copyBBTouchSources" if="bbtouch">
    <echo message="Copying blackberry touch sources"></echo>
    <copydir forceoverwrite="true" src="$%7Bproject.BlackberryPort%7D%5Cbuild%5Ctouch%5Cpreprocessed" dest="${basedir}/${preprocessed.dir}">
    <touch file="${basedir}/${preprocessed.dir}/com/sun/lwuit/M3G.java">
    <touch file="${basedir}/${preprocessed.dir}/com/sun/lwuit/SVGImage.java">
    <touch file="${basedir}/${preprocessed.dir}/com/sun/lwuit/animations/Transition3D.java">
    <touch file="${basedir}/${preprocessed.dir}/com/sun/lwuit/impl/midp/SVGImplementation.java">
    </touch>

    <target name="copyBBSources" if="do.rapc">
    <echo message="Copying blackberry sources ${preprocessed.dir}"></echo>
    <copydir src="$%7Bproject.LWUIT%7D%5Csrc" dest="${basedir}/${preprocessed.dir}">
    <copydir forceoverwrite="true" src="$%7Bproject.BlackberryPort%7D%5Cbuild%5Cpreprocessed" dest="${basedir}/${preprocessed.dir}">
    <touch file="${basedir}/${preprocessed.dir}/com/sun/lwuit/M3G.java">
    <touch file="${basedir}/${preprocessed.dir}/com/sun/lwuit/SVGImage.java">
    <touch file="${basedir}/${preprocessed.dir}/com/sun/lwuit/animations/Transition3D.java">
    <touch file="${basedir}/${preprocessed.dir}/com/sun/lwuit/impl/midp/SVGImplementation.java">
    </touch>

    <target name="post-jar" if="do.rapc">
    <rapc verbose="true" output="${name}" jdehome="${platform.home}" import="${platform.bootclasspath}" destdir="${platform.home}/simulator/" noconvert="true">
    <src location="${basedir}/${preprocessed.dir}">
    <jdp title="Vendor" version="1" type="cldc" icon="${basedir}/src/icon.png" />
    </jdp>
    </src>

    <target name="post-clean">
    <delete failonerror="false">
    <fileset dir="${platform.home}/simulator">
    <include name="**/${name}.*">
    </include>
    </fileset>
    </delete>
    </target>
